13-48-C Series Kitchen Range Hood Exhaust Centrifugal Fan

13-48-C Series Kitchen Range Hood Exhaust Centrifugal Fan

1.Typical Feature and Application

• 13-48-C Series heavy duty centrifugal fan is equipped with integral bearing seat, strong bearing capacity and long service life. The impeller and bearings can be serviced and maintained without removing the air duct.

• 13-48-C Series heavy duty centrifugal fan operate with low noise and are suitable for quiet environments such as commercial buildings, data centers and medical facilities.

• 13-48-C Series heavy duty centrifugal fan has two structural forms for users to choose from: the motor is mounted on the top of the housing and the motor is mounted on the base.

• 13-48-C Series heavy duty centrifugal fan is suitable for kitchen smoke exhaust, air conditioning units, hotels, restaurants and other occasions, with novel and compact structure, small vibration, convenient adjustment and so on.

• Under the heat dissipation demand of high load, 13-48-C Series heavy duty centrifugal fan takes away heat through high efficiency air flow, which is helpful to the stable operation of electronic equipment and industrial machines ‌

• 13-48-C Series centrifugal ventilator has 4C, 4.5C, 5C, 5.6C, 6.3C 5 machine numbers, users can choose the right machine number according to specific needs.

2. Performance Range

3.Product Description

     13-48-C heavy centrifugal fan is a special fan for cabinet fume purification derived from 13-48-A fan. The C-type belt drive can adjust the performance parameters of the fan by changing the transmission ratio of the belt pulley.

• Bearings: 13-48-C heavy centrifugal fan adopts imported bearings, quality and service life are more guaranteed.

• Refueling nozzle: 13-48-C heavy duty centrifugal fan shell is equipped with refueling nozzle, bearing can be refueling without removing the pipeline, making daily maintenance more convenient. Regular refueling and maintenance of bearings can ensure the duration of service life.

• Oil drain hole: 13-48-C heavy duty centrifugal fan shell is provided with oil drain hole, installation can be connected to the oil pipe, so that the liquid flow from the oil drain nozzle, thereby reducing the number of liquid cleaning.

• Cleaning door: The cleaning door is designed on the 13-48-C heavy centrifugal fan housing, the user does not need to remove the fan to clean and maintain the impeller, just open the cleaning door, saving time and effort.

• 13-48-C heavy duty centrifugal fan motor mounted on the top of the housing, compact structure, less space. Can realize 0°, 90°, 180°, 270° four Angle interchange.

• 13-48-C heavy centrifugal fan motor is installed on the base structure, the fan stability is good, especially suitable for large fans, but the area is relatively large. The three angles of 0°, 90° and 180° can be exchanged.

4.Fan Operation

• Determine the installation position; The best installation location of the 13-48 Series centrifugal air mover should be selected according to the characteristics and needs of the workplace. The installation position should be a certain distance from the wall, ceiling and other obstacles to ensure the normal operation of the fan.

• Mounting bracket; According to the model and size of the 13-48 Series commercial kitchen exhaust fan, select the appropriate bracket for installation. The support needs to have sufficient strength and stability to carry the weight and vibration of the commercial kitchen exhaust fan. When installing the bracket, keep it horizontal and vertical to avoid tilting or shaking.

• Connecting pipes; According to the actual needs, choose the appropriate pipe to connect the 13-48 Series commercial kitchen exhaust fan. The connection of the pipeline should be tight and reliable to prevent air leakage and pressure loss. At the same time, it is also necessary to ensure that the path of the pipeline is smooth to avoid bending and blocking.

• Fixed centrifugal fan; After the installation position and bracket are determined, the 13-48 Series commercial kitchen exhaust fan is fixed on the bracket. The fastening method can be bolted or welded to ensure that the connection between the fan and the support is firm and reliable.

• Adjust the fan Angle; After the installation is completed, the Angle of the 13-48 Series commercial kitchen exhaust fan needs to be adjusted according to the actual needs. Adjusting the fan Angle can change the wind direction and wind pressure to meet different ventilation requirements.

• Connect the power supply; The last step is to connect the power supply to the 13-48 Series commercial kitchen exhaust fan. Before connecting the power supply, ensure that the power supply is stable and reliable to ensure the normal operation of the centrifugal fan. At the same time, wiring should be carried out in accordance with electrical safety standards to avoid electrical failures and hazards.

5.Fan Certificate and Quality Control

     By our efforts, our company Gaoze was selected as the member of China General Machinery Industry Association Ventilation Fan Branch. Our products enjoy good reputation among our customers.  Our Products were awarded as "Brand-name and High Quality Products" by "China Quality Evaluation Center" &"Guangdong Branch of Social Servey Institute China"; Furthermore, a number of products are applied patents, which are up to the advanced standard. We are "Guangdong Private Scientific and Technological Enterprise" and past the "National Industrial Products License Certificate". Energy saving axial duct fan and multi-blade centrifugal fan developed by our company obtained the standard certification, most of our products past the certificate of "CCC" and "CE".  We are fully implementing ISO 9001:2008 Quality System.

6.Fan Maintain

• Regularly clean the inside and outside of the 13-48 Series commercial kitchen exhaust fan to prevent ash accumulation.

• For 13-48 Series commercial kitchen exhaust fan equipped with filter devices, check and clean the filter screen regularly to avoid dust clogging the filter screen and affecting the ventilation effect.

• Regularly check whether the motor and transmission parts of 13-48 Series commercial kitchen exhaust fan are working properly, and replace the worn parts in time.

• Regularly add lubricating oil to the lubricating transmission parts of the 13-48 Series commercial kitchen exhaust fan to reduce friction and wear.

7.Technical Specification

8.Packing Detail

Film Packing: a cost-effective packing method, it is suggested when order is one full container.

Plywood Box Packing: more safe packing, it is suggested when order is not enough one full container.
